Name: DC Audio Level 5 12"
Brand: DC Audio - SHCA
SKU: DCA-LVL5-12-D.7
Price: 1054.99 USD
Availability: InStock

$1,054.99

Free shipping*

Here it is, the m5 version of the Lv5 subwoofer. Built for ground pounding and taking abuse in or out of the competition lanes.

When we went to the drawing board with this one we were looking to make improvements in cooling, motor force and soft parts, With the AR surround / Cone, solid pole, machined cooling vents, 10” Spiders and a 3.5" coil we accomplished all of those things and then some.

The end result is a sub that works great in the SPL lanes as well as Pounding out the LOWS!!

To really step it up with this driver take a look at the Carbon Fiber options available for it.

The end result is a sub that has extreme amounts of output for the SPL lanes but reliable enough for a high-powered daily system.

Key Features

Extremely strong kraft pulp fiber reinforced cone

• Wide Long Throw foam surround

• Dome propylene dust cover with White DC logo

• 10” OD Spaced Spiders

• Extra heavy duty sewn tinsel lead wire

• Cast DC Series aluminum black frame 15”/18”

• FEA analyzed and optimized motor assembly – Fully CNC machined

• Rubber mounting gasket

• Direct Leads

• DVC 3.5” 8 Layer Hi-temp Aluminum voice coil wound on a Black Anodized Aluminum voice coil former with high current input strips.

Sub Size	12"	15"	18"
Mounting Depth	10.50"	11.75"	12.75"
Mounting Hole Diameter	11.15"	14.25"	16.90"
Outside Driver Diameter	12.50"	15.70"	18.50"
Motor Width	9.84"	9.84"	9.84"
Shipping Weight	89lbs	95lbs	107lbs
VC Diameter	3.50"	3.50"	3.50"
Displacement	.19³ ft	.21³ ft	.26³ ft
Magnet Weight	79.5lbs	79.5lbs	79.5lbs
Power Handling RMS/Peak	3000 / 6000	3500 / 7000	3500 / 7000
Impedance (Ohm)	D.7 / D1 / D1.4 / D2	D.7 / D1 / D1.4 / D2	D.7 / D1 / D1.4 / D2
Sd	494.00 cm²	815.00 cm²	1217.00 cm²
Vas	Coming Soon	Coming Soon	Coming Soon
Cms	Coming Soon	Coming Soon	Coming Soon
Mms	Coming Soon	Coming Soon	Coming Soon
Fs	Coming Soon	Coming Soon	Coming Soon
BL	Coming Soon	Coming Soon	Coming Soon
Re	Coming Soon	Coming Soon	Coming Soon
Le	Coming Soon	Coming Soon	Coming Soon
Qms	Coming Soon	Coming Soon	Coming Soon
Qes	Coming Soon	Coming Soon	Coming Soon
Qts	Coming Soon	Coming Soon	Coming Soon
Xmax	Coming Soon	Coming Soon	Coming Soon
Ref SPL @ 1 watt	Coming Soon	Coming Soon	Coming Soon
Suggested Sealed	N/A	N/A	N/A
Suggested Ported	1.5³ ft	3.0³ ft	5.5³ ft

As soon as your item is ready to ship you will receive an email with tracking information. We use FedEx, UPS and YRC Freight for all shipments.

*Shipping is free in the lower 48 states, unless otherwise stated.
