M8S - 8" 140 Watt 4 Ohm Mid-Range Shallow Mount Speaker - GARAGE SALE
Built to order, ships in 2-3 weeks.
FREE shipping to the lower 48
M8S - 8" 140 Watt 4 Ohm Mid-Range Shallow Mount Speaker - GARAGE SALE
Product details
Description
Used M8s pulled out of the stereotype build, Sold as Pairs
SOLD AS IS. NO REFUNDS. SHIPPING INCLUDED.
| Nominal Basket Diameter | 8.3", 210mm |
| Nominal Impedance | 4 Ohms |
| RMS Watts | 140 W |
| Music Program | 300 W |
| Resonance | 100 Hz |
| Usable Frequency Range | 100Hz-7KHz |
| Sensitivity | 98 dB |
| Magnet Weight | 2.1 oz |
| Gap Height | 0.24", 6mm |
| Voice Coil Diameter | 1.5â€, 38.5mm |
| Resonant Frequency (fs) | 138 Hz |
| DC Resistance (Re) | 2.6 |
| Mechanical Q (Qms) | 0.603 |
| Overall Diameter | 8.3", 210mm |
| Mounting Holes Diameter | 0.22", 5.5mm |
| Mounting Holes | B.C.D. 7.72", 196mm |
| Depth | 2.36", 60mm |
| Basket Materials | Cast Aluminum |
| Cone Composition | Paper Cone |
