DC Audio - SHCA

DC Audio Level 1 10"

$139.99
/
  • Free shipping*

Key Features
• Extremely rigid non-pressed paper cone assembly
• Multilayered polymer wide roll foam surround
• Polypropylene dust cover with embossed DC logo
• 8” OD flat linear roll spider
• Heavy duty interweaved tinsel lead wire sewn to the spider
• Cast aluminum black frame
• FEA analyzed and optimized motor assembly - Fully CNC machined
• Rubber mounting gasket
• Chrome spring loaded push terminals
• 2” Hi-temp copper voice coil wound on black anodized voice coil former
• Rubber magnet cover

  10" 12"
Mounting Depth 5.5" 6"
Mounting Hole Diameter 9.35" 11"
Outside Driver Diameter 11.0" 12.5"
Weight 18lbs 18.5lbs
VC Diameter 2" 2"
Displacement
Magnet Weight 15lbs 15lbs
Power Handling RMS/Peak 300/600 300/600
Impedance (Ohm) D2 or D4 D2 or D4
Sd 78.5 in^2  78.5 in^2
Vas

1.26 (ft^3)

1.26 (ft^3)


Cms
Mms

162.2 g

162.2 g


Fs

40.0 Hz

40.0 Hz


BL
Re

8.20 Ohms

8.20 Ohms


Le
Qms

2.27

  2.27
Qes

0.75

0.75


Qts

0.56

0.56


Xmax
Ref SPL @ 1 watt
Suggested Sealed .5³ ft .75³ ft
Suggested Ported  1.0³ ft 1.25³ ft

As soon as your item is ready to ship you will receive an email with tracking information. We use FedEx, UPS and YRC Freight for all shipments.

*Shipping is free in the lower 48 states, unless otherwise stated.
